WELCOME TO BOX ENCLOSURES

A leading supplier of off-the-shelf enclosures for over 30 years. All enclosures IN STOCK for immediate delivery Hand Held - Extruded Aluminum - Outdoor NEMA - Desk Top - Many Battery Options Available

Mobile Box Small - 9V or 2AA Battery Configuration, 9 Volt Battery

Mobile Box Small: Features a recessed area for membrane keypad and holds 2 - AA or 1 - 9V battery cells. Material is Off-White / Black ABS.  Optional NEMA 4 sealing kit available.


Window Version #

LCD Window Size

Version 1

Part # MBS-109 / 107 - No LCD Window with recessed top

Version 2

Part # MBS-209 / 207 - 1.79 x 0.70" for 2 x 16 display

Version 3

Part # MBS-309 / 407 - 1.76 x 0.36" for 2 x 20 display

Version 4

Part # MBS-409 / 407 - 1.76 x 0.69 for 4 x 16 display

Technical Drawings:

Product Details:

Part Number: MBS

Size in Inches: 5.98L x 3.26W x 1.31H"

Size in mm: 152L x 83W x33H mm

Battery Type: 9 Volt or 2AA

Weight-Lbs: 0.2

Material: ABS: UL 94 HB or UL 94 VO

RoHS Compliant: Yes

Protection Class: IP65 / NEMA 4 [X] with Sealing Kit

In Stock - Ships in 24 Hours or Less

Price Brackets:

Quantity Price
1 - 99 $12.00
100 - 249 $9.36
250 - 499 $7.72
500 - 999 $6.40
1000 -2500 $6.00

Description

Part Number MBS
Product Name Mobile Box Small - 9V or 2AA Battery Configuration, 9 Volt Battery
Battery Type 9 Volt or 2AA
Color Black,White
Size 5.98x3.26x1.31"
Material ABS: UL 94 HB or UL 94 VO
Weight in Pounds 0.2
Technical Drawings:
Price Brackets
Quantity Price
1 - 99 $12.00
100 - 249 $9.36
250 - 499 $7.72
500 - 999 $6.40
1000 -2500 $6.00

Additional Information

Weight 0.2 lbs
Dimensions 5.98L x 3.26W x 1.31H"
Meterial ABS: UL 94 HB or UL 94 VO

Why Box Enclosures?

Box Enclosures, Inc. is a full service designer, manufacturer and supplier of injection molded plastic enclosures, handheld electronic enclosures, instrument cases and anodized extruded aluminum enclosures. We produce a complete line of off-the-shelf injection molded enclosures, semi-custom and custom hand-held enclosures and cases.
